1/4" Dr 32 - 80 In Oz Tohnichi Preset Torque Screwdriver - RNTD60CN
Now:$190.10
MSRP:$202.59
(You save $12.48 )
- SKU:RNTD60CN & NIST CERT
- Condition:New
- Drive Size:1/4 Inch
- Range In Oz:32 - 80
- Range cNm:20 - 60
- Accuracy:3%
- Made In:Japan
Product Description
The Tohnichi RNTD60CN preset torque screwdriver accepts universal 1/4-inch drive bits and can be preset in an English range of 2-5 In Lbs or 20-60 cNm.
Features
- Preset torque screwdriver with rotary-slip mechanism to prevent over-tightening.
- Accuracy ± 3%
- Preset style is ideal for applications which require the same torque setting such as assembly work.
- No external scale adjustment means torque set cannot be inadvertently changed making for more secure torque setting.
- Supplied with no torque set. Requires adjusting key and tester to set torque value.
- Preset torque service can be requested at time of order for a nominal fee.
- Enhanced reliability and durability by adopting toggle clutch torque mechanism.
- User will sense "click" at set torque. If user continues past the click, the tool will ratchet without applying additional torque.
- Accepts standard 1/4 hex root bits. (sold separately)
- Certificate of calibration traceable to NIST included.
Specifications
Accuracy ± 3% | ||||||||
MODEL | RNTD60CN | |||||||
TORQUE RANGE [cN • m] | MIN.~MAX. | 20~60 | ||||||
TORQUERANGE [kgf • cm] | MIN.~MAX. | 2~6 | ||||||
TORQUE RANGE [lbf • in] | MIN.~MAX. | 2~5 | ||||||
APPLICABLE SCREW | SMALL SCREW | M2.5, M3 | ||||||
TAPPING SCREW | (M2.2)M2.5 | |||||||
DIMENSION [mm] | OVERALL LENGTH | L' | 95 | |||||
GRIP | D1 | 19.5 | ||||||
BODY COLOR | Black | |||||||
BODY | D4 | 11 | ||||||
L1 | 24 | |||||||
L2 | 59 | |||||||
WEIGHT [kg] | 0.07 |
Made in Japan
