1/4" Dr 32 - 80 In Oz Tohnichi Preset Torque Screwdriver - RNTD60CN

$209.11
$222.85
  • SKU:RNTD60CN & NIST CERT
  • Condition:New
  • Drive Size:1/4 Inch
  • Range In Oz:32 - 80
  • Range cNm:20 - 60
  • Accuracy:3%
  • Made In:Japan
Product Description


The Tohnichi RNTD60CN preset torque screwdriver accepts universal 1/4-inch drive bits and can be preset in an English range of 2-5 In Lbs or 20-60 cNm.

Features

  • Preset torque screwdriver with rotary-slip mechanism to prevent over-tightening.
  • Accuracy ± 3%
  • Preset style is ideal for applications which require the same torque setting such as assembly work.
    • No external scale adjustment means torque set cannot be inadvertently changed making for more secure torque setting.
  • Supplied with no torque set. Requires adjusting key and tester to set torque value.
  • Preset torque service can be requested at time of order for a nominal fee.
  • Enhanced reliability and durability by adopting toggle clutch torque mechanism.
  • User will sense "click" at set torque. If user continues past the click, the tool will ratchet without applying additional torque.
  • Accepts standard 1/4 hex root bits. (sold separately)
  • Certificate of calibration traceable to NIST included.

Specifications

Accuracy ± 3%
MODEL RNTD60CN
TORQUE RANGE
[cN • m]
MIN.~MAX. 20~60
TORQUERANGE
[kgf • cm]
MIN.~MAX. 2~6
TORQUE RANGE
[lbf • in]
MIN.~MAX. 2~5
APPLICABLE SCREW SMALL SCREW M2.5, M3
TAPPING SCREW (M2.2)M2.5
DIMENSION
[mm]
OVERALL LENGTH L' 95
GRIP D1 19.5
BODY COLOR Black
BODY D4 11
L1 24
L2 59
WEIGHT [kg] 0.07

product dimensions

Made in Japan
