Norbar

3/4" Dr 100 - 1000 Nm Norbar HT-52/4.7 Hand Torque Multiplier - 181440

$1,615.23
$1,863.72
  • SKU:181440
  • UPC:5060922235978
  • Condition:New
  • Drive Size:3/4 Inch
Product Description

Norbar

3/4" Dr 100 - 1000 Nm Norbar HT-52/4.7 Hand Torque Multiplier - 181440

The Norbar 'Compact Series' Handtorque multipliers are smaller and lighter than other torque multipliers. They are supplied with a unique calibration certificate and in their own carry case. This 4.7:1 ratio model is one of the smallest in the world for its output capacity.

Features

  • Guaranteed accuracy of better than +/-4%.
  • 52mm diameter allows excellent access.
  • Each multiplier is supplied with its own unique calibration certificate allowing the accurate calibration of input torque for critical application. Calibrated from 20% of maximum capacity.
  • Tool Weight: 1.0 Kg
  • Multiplication Ratio: 4.7:1
  • Output Square: 3/4"
  • Input Square: 1/2"
  • Plate Weight: 0.9 Kg
  • Accuracy: ±4%
  • Operates between: 100.00 - 1000.00 N·m
