2 1/2" Dr 2500 - 25000 Ft Lbs Norbar Smart Static Torque Transduce - 50798.LOG
2 1/2" Dr 2500 - 25000 Ft Lbs Norbar Smart Static Torque Transduce - 50798.LOG
2 1/2" Dr 2500 - 25000 Ft Lbs Norbar Smart Static Torque Transduce - 50798.LOG
2 1/2" Dr 2500 - 25000 Ft Lbs Norbar Smart Static Torque Transduce - 50798.LOG

2 1/2" Dr 2500 - 25000 Ft Lbs Norbar Smart Static Torque Transduce - 50798.LOG

Price:$13,540.73
  • SKU:50798.LOG
  • UPC:5060922234759
  • Condition:New
  • Drive Size:2 1/2 Inch
Product Description

Norbar

2 1/2" Dr 2500 - 25000 Ft Lbs Norbar Smart Static Torque Transduce - 50798.LOG

The accuracy and quality of the Norbar Static Torque Transducers has made them the first choice of many calibration laboratories throughout the world.

Features

  • Robust, heat treated, alloy steel torsion shaft design.
  • Designed to ignore non torsional forces.
  • Operates in clockwise and anti-clockwise directions.
  • Calibrated in clockwise direction as standard. Anti-clockwise calibration provided on request.
  • 'SMART' transducers can also be used with many instruments not of Norbar manufacture. However, these will operate as normal ratio calibrated (mV/V) transducers - the 'SMART' data will not be read. For non Norbar instruments or for when a mV/V certificate is required, use part code suffix '.IND'.
  • Calibration up to 100,000 N·m with UKAS Certificate.
  • Weight: 13 Kg
  • Temp Range Operating: -10°C to +50°C
  • Temp Range Storage: -20°C to +70°C
  • Thermal Effect On Span: < +/- 0.03%/°C
  • Thermal Effect On Zero: < +/- 0.01%/°C
  • Torsional Deflection: < 1°
  • Fatigue: > 10 exp 7 cycles
  • Maximum Torsion Capacity: 150%
  • Connector: 6 Way Mil Spec
  • Drive 1: 2 1/2" Male Square
  • Drive 2: 2 1/2" Male Square
  • Operates between: 2500.00 - 25000.00 lbf·ft
