5,000 Ft Lbs 1 1/2" Dr Williams 26.5:1 Plate Reaction Torque Multiplier - TM-394
Now:$6,468.32
MSRP:$14,607.78
- SKU:JHWTM-394
- UPC:66245926129
- Condition:New
- Drive Size:1 1/2 Inch
- Max Ft Lbs:5000
- Max Nm:6779
- Torque Ratio:26.5:1
- Weight Lbs:22.5
Product Description
The Williams TM-394 Plate Reaction torque multiplier offers a torque ratio of 26.5:1 and a maximum output of 5,000 Ft Lbs or 6,779 Nm.
Torque Multiplier Tool Features:
- Designed where high torques are necessary for fastening or breaking out stubborn fasteners.
- Allows operator safe and easy means of producing torque for job requirements.
- Precision planetary gear multiplies the operator's input from standard torque wrenches.
- Can also multiply the torque from air-Driven (non-impact) wrenches
- Max Output Ft. Lbs.: 5000
- Input Cap: 189
- Gear Ratio: 29.25:1
- Torque Ratio: 26.5:1
- Input Sq. Size: 1/2"
- Output Sq. Size: 1 1/2"
- Overall Length: 14 27/32
- Head Height Sq. to Top: 8 3/4
- Head Dia.: 5 1/2
