3/4'' Dr 60 - 600 Ft Lbs / 81.3 - 813 Nm Williams Digital Torque Tester - 6004-F-DTTW
- SKU:6004-F-DTTW
- Condition:New
- Drive Size:3/4 Inch
- Range Ft Lbs:60 - 600
- Range Nm:81.3 - 813
- Accuracy:0.5%
Product Description
The Williams 6004-F-DTTW Digital Torque Tester has a 3/4 Inch Drive and can test ranges an English range of 60-600 Ft Lbs and Metric ranges between 81.3 - 813 Nm and 8.30 - 83 kgm. The DTT Utilizing the testing protocol and standards developed by the American Society of Mechanical Engineers (ASME)
The Williams 6004-F-DTTW is designed to be an affordable torque tester that can be mounted on a wall or used in a bench-top vise to allow the operator to conveniently test torque wrenches and torque screwdrivers. This 3/4" drive digital torque tester features an easy to use touch pad screen to capture peak torque values during a test in real time, and download stored torque data to a PC. All DTT torque wrench testers are sold in a kit with the tester, carrying case and AC/DC power supply.
Features:
- Test the health of your torque wrenches and screwdrivers anywhere
- For manufacturing/assembly, process control and data collection
- Can be mounted on a wall or in a bench-top vise
- Features an easy-to-use touchscreen to capture peak torque values during a test in real time
- Sold as a kit with the tester, carrying case and AC/DC power supply
- Ability to customize between units of measure (ft-lb, in-lb, in-oz, Nm, kg-cm), operating mode (Track, Peak, First Peak) and wrench type
- Includes Certificate of Calibration
- Highly accurate scale (±0.5% ±1 count 10-100% CW and CCW of indicated test value @ 25 °C)
- ±0.5 of indicated test value from 10-100% or rated capacity
- Units of Measure: ft-lb, in-lb, in-oz, Nm, kg-cm
- Operating Modes: Peak, First Peak, Track
- Operating Temperature: 50 to 90 °F (10 to 32 °C)
- Storage Temperature: -2 to 122 °F (-20 to 50 °C)
- Humidity: 85% Relative Humidity @70 °F (21 °C)
- Power Supply: Included 9 V AC/DC adaptor, 6 AA batteries included
- Memory Capacity: 500 records (complete check mode only)
- Dimensions: 16" x 10" x 2.5"
- Weight (tester only): 10.7 lbs
