- SKU:RH22DX27
- Condition:New
- Scale:Metric
- Type:Ring
Product Description
The RH Ring Head - RH22DX27
Tohnichi's interchangeable head wrenches have specific diameter round ends that fit into corresponding head base openings. Head and wrench model names include the diameter sizes so that heads can be matched to wrenches that accept those heads. With the large selection of head styles available, wrenches such as CL (for tightening) and CEM3 (for measuring) can use the same head that has the same root diameter--making interchangeable head wrenches an economical and flexible tool choice.
Features:
| Model | Allowable Torque | Outside Width | Thick- ness | Length | Applicable Models |
| (Head Size X Width) | [N.m] | [mm] | [mm] | [mm] | |
| RH22D X 27 | 190 | 41 | 17 | 100 | CL280N, 420N/CSP, PCL420N CDB100N-S, 420-S CF230N CEM360N2, 500N2 CTAE360 ~ 500/CTAE-P/CTBE |
Note:
- The RH type ring heads guarantee the safe work as the axes of bolt and RH ring head are always aligned and prevent the heads will drop.
Made In Japan
