44.3-221.2 In Lbs / 5 - 25 Nm Tohnichi Interchangeable Head Preset Torque Wrench - CSP25N3x10D
Now:$189.19
MSRP:$200.10
- SKU:CSP25N3x10D+Cert
- Condition:New
- Type:Preset
- Wrench can be preset between:44.3-221.2 In Lbs
- Wrench can be preset between:5 - 25 Nm
- Max In Lbs:221.2
- Max Nm:25
- Length:7.5"
- Accuracy:3%
- Drive Size:8D
- Made In:Japan
Product Description
The Tohnichi Interchangeable Head Preset Torque Wrench - CSP25N3x10D can be preset within an English range of 44.3-221.2 In Lbs or a Metric range of 5 - 25 Nm and works with Tohnichi 10D interchangeable heads.
Features:
- Interchangeable Head Version of QSP
- No External Scale, Torque Value Set Using Key & Tester
- CSPLS with Limit Switch version for torque verification to PLC/or CNA-4mk2 Count
| Model | Torque Range | Hand Force at Max Torque | Dimensions [mm] | Weight approx. | Tohnichi Head Size | Handle Color/Style | Adjusting Key | Options | |||||||
| d3 | |||||||||||||||
| Min.-Max. | Effective Length | Overall Length | Body | ||||||||||||
| S.I. | American | N | L | L' | m | n | d | D | kg | Selection | Carrying Case | Colored Grips | |||
| CSP25N3x10D | N.m 5-25 |
in.lbs 44.3-221.2 |
130 | 186 | 195 | 19 | 9.2 | 15 | 29 | 0.2 | 10D | Black Rubber | #931 | N/A | Yes |
Note:
- Overall length does not include interchangeable head.
- A torque wrench tester and adjusting key are required to set torque.
Made In Japan
