1/4" Hex 10 - 40 In Lbs Tohnichi Slip Type Adjustable Torque Driver - RTD40I
1/4" Hex 10 - 40 In Lbs Tohnichi Slip Type Adjustable Torque Driver - RTD40I
1/4" Hex 10 - 40 In Lbs Tohnichi Slip Type Adjustable Torque Driver - RTD40I
1/4" Hex 10 - 40 In Lbs Tohnichi Slip Type Adjustable Torque Driver - RTD40I

1/4" Hex 10 - 40 In Lbs Tohnichi Slip Type Adjustable Torque Driver - RTD40I

Now:$245.07
MSRP:$250.05
(You save $4.98 )
  • SKU:RTD40I
  • Condition:New
  • Drive Size:1/4 Inch
  • Range In Lbs:10 - 40
  • Length:6.10"
  • Weight:0.32 Kg
  • Accuracy:3%
  • Made In:Japan
Product Description


The Tohnichi RTD40I is a 10-40 in lb adjustable torque screwdriver has a 1/4" female hex drive.

Used for any tightening operation such as mass production assembly and maintenance. The rotary slip clutch reduces the possibility of over-torque. Once torque set is achieved, even if more force is applied, the tool ratchets and does not add additional torque.

Features:

  • Adjustable torque setting by twisting shaft with main and supplementary scales
  • Models are available in SI, Metric or English units of measure --one unit of measure on tool
  • Lock ring holds selected torque value in place
  • For Clockwise tightening only
  • Click alerts user that torque set has been achieved
  • Rotary slip mechanism prevents over torque by ratcheting after click
  • Accuracy +/-3% of indicated value
  • Mid range models have removable colored resin grip
  • Large models includes hook to assist with turning shaft to set tool for higher values.
  • Accepts 1/4 hex bits (not included) See Accessories tab above
  • Includes Tohnichi Factory Certificate of Calibration
  • (NIST Traceable Certificate of Calibration offered for additional fee)
MODEL TORQUE RANGE Dimensions [mm] Weight Approx.
Overall Length Grip Body
New Model Name min.-max. Graduation L' D1 D2 D3 D4 L1 L2 kg
New AMERICAN AMERICAN
RTD40I in·lbs
10-40
in·lbs
0.5
155 33 26 11 41 24 129-141 0.32

Note:

  • This series accepts standard 6.35 (1/4) hex bits, sold separately.

RTD

 Made In Japan
