Tohnichi 30 - 300 Ft Lbs Interchangeable Head Dial Torque Wrench - 4200CDB-A-S

Tohnichi 30 - 300 Ft Lbs Interchangeable Head Dial Torque Wrench - 4200CDB-A-S

$540.55 $569.00
(You save $28.45)
Model #
4200CDB-A-S
Condition:
New
Range for this wrench:
30 - 300 Ft Lbs
Length:
36.4"
Accuracy:
± 3%
Scale:
Ft Lbs to 300
Type:
Dial

Description


The Tohnichi 4200CDB-A-S has a range of 30 - 300 Ft Lbs and uses Tohnichi size 22D heads.

Features

  • Accuracy ± 3%.
  • Easily exchange different head types for various applications such as ring head, open end head, and ratchet. (See full selection of available heads in accessories section below)
  • Lightweight, easy-to read large scale features follower hand memory pointer that captures peak torque
  • Since the amount of deformation is small, the operator's fatigue is reduced compared to the flat beam type torque wrench.
  • The dial is movable making it easy to adjust the zero point, or use for tightening by moving dial to desired torque and tightening to "0"
  • The dial indicator has a full-surround protective cover to prevent damage to external objects (except CDB300N, 420N).
  • Low range models have handle designed to guide operator to use index finger to apply lighter force to avoid possible over torque
  • Includes certificate of calibration compliant with calibration procedures of ISO 6789 Type I Class B.

Specifications

Accuracy ± 3%
AMERICAN MODEL 4200CDB-A-S
TORQUE RANGE
[lbf • in/lbf • Ft]
MIN.~MAX. 30~300
GRAD. 5
APPLICABLE BOLT
(REFERENCE)
STEEL M24
HEIGHT TENSION (M18)
MAX. HAND FORCE [N] 454.1
DIMENSION

EFFECTIVE LENGTH L 36.4"
OVERALL LENGTH L' 36.2"
HEIGHT H 2.5"
HEAD d3 .8"
WEIGHT [lbs] 5.9

product dimensions

Notes

Overall length does not include interchangeable head. PH (Pipe wrench head) type interchangeable head is not available for this model.

Interchangeable Heads Available For This Wrench:

qh8d-70869.jpg sh32dx27-36656.jpg rh32dx27-23098.jpg rqh22dx22-27152.1489781742.jpg
fh22dx75-21644.1489966212.190.250.jpg dh22d-30636.1489965567.190.250.jpg hh22dx12-60929.1489965920.190.250.jpg

Made in Japan



Warranty Information

All Tohnichi products are thoroughly checked and tested at the factory before shipment. The accuracy of each tool should be as stated for each model as a percentage of reading unless otherwise noted. Hand tool durability is based on repeated movement tests over a minimum of 100, 000 cycles by a durability testing machine. Should defects due to faulty materials and workmanship develop within one (1) year from the date of sale, it will be repaired and put in workable condition or replaced free of charge if returned to Tohnichi with proof of purchase. The warranty is not valid if the product has been misused, tampered with, or abused.
